New tool gives structural strength to 3-D printed works

September 18, 2012


Bedrich Benes 3-D printing

Bedrich Benes, an associate professor of computer graphics at Purdue University, is working with Advanced Technology Labs of Adobe Inc. to develop a computer program that automatically strengthens objects created using 3-D printing. The innovation is needed because the printed fabrications are often fragile and fall apart or lose their shape, as evidenced by some of the failed or misshapen objects on display here. (Purdue University photo/Mark Simons)
Download Photo

WEST LAFAYETTE, Ind. – Objects created using 3-D printing have a common flaw: They are fragile and often fall apart or lose their shape.

"I have an entire zoo of broken 3-D printed objects in my office," said Bedrich Benes, an associate professor of computer graphics at Purdue University.

The printed fabrications often fail at points of high stress.

"You can go online, create something using a 3-D printer and pay $300, only to find that it isn't strong enough to survive shipping and arrives in more than one piece," said Radomir Mech, senior research manager from Adobe's Advanced Technology Labs.

The 3-D printers create shapes layer-by-layer out of various materials, including metals and plastic polymers. Whereas industry has used 3-D printing in rapid prototyping for about 15 years, recent innovations have made the technology practical for broader applications, he said.

"Now 3-D printing is everywhere," Benes said. "Imagine you are a hobbyist and you have a vintage train model. Parts are no longer being manufactured, but their specifications can be downloaded from the Internet and you can generate them using a 3-D printer."

The recent rise in 3-D printing popularity has been fueled by a boom in computer graphics and a dramatic reduction of the cost of 3-D printers, Benes said.

 Researchers at Purdue and Adobe's Advanced Technology Labs have jointly developed a program that automatically imparts strength to objects before they are printed.

"It runs a structural analysis, finds the problematic part and then automatically picks one of the three possible solutions," Benes said.

Findings were detailed in a paper presented during the SIGGRAPH 2012 conference in August. Former Purdue doctoral student Ondrej Stava created the software application, which automatically strengthens objects either by increasing the thickness of key structural elements or by adding struts. The tool also uses a third option, reducing the stress on structural elements by hollowing out overweight elements.

"We not only make the objects structurally better, but we also make them much more inexpensive," Mech said. "We have demonstrated a weight and cost savings of 80 percent."

The new tool automatically identifies "grip positions" where a person is likely to grasp the object. A "lightweight structural analysis solver" analyzes the object using a mesh-based simulation. It requires less computing power than traditional finite-element modeling tools, which are used in high-precision work such as designing jet engine turbine blades.

"The 3-D printing doesn't have to be so precise, so we developed our own structural analysis program that doesn't pay significant attention to really high precision," Benes said.

The paper was authored by Stava, now a computer scientist at Adobe, doctoral student Juraj Vanek; Benes; Mech; and Nathan Carr, a principal scientist at Adobe's Advanced Technology Labs.

Future research may focus on better understanding how structural strength is influenced by the layered nature of 3-D-printed objects. The researchers may also expand their algorithms to include printed models that have moving parts.

A video demonstrating the new program is available at http://www.youtube.com/watch?v=J8bPXk5od4I&feature=plcp

Writer: Emil Venere, 765-494-4709, venere@purdue.edu

Source: Bedrich Benes, 765-496-2954, bbenes@purdue.edu

Note to Journalists: The research paper is available from Emil Venere, 765-494-4709, venere@purdue.edu


 ABSTRACT

Stress Relief: Improving Structural Strength of 3-D Printable Objects

Ondrej Stava1 Juraj Vanek1 Bedrich Benes1 Nathan Carr2 Radomır Mech2

1 Purdue University 2 Adobe Systems Incorporated

The use of 3-D printing has rapidly expanded in the past couple of years. It is now possible to produce 3-D-printed objects with exceptionally high fidelity and precision. However, although the quality of 3-D printing has improved, both the time to print and the material costs have remained high. Moreover, there is no guarantee that a printed model is structurally sound. The printed product often does not survive cleaning, transportation, or handling, or it may even collapse under its own weight. We present a system that addresses this issue by providing automatic detection and correction of the problematic cases. The structural problems are detected by combining a lightweight structural analysis solver with 3-D medial axis approximations. After areas with high structural stress are found, the model is corrected by combining three approaches: hollowing, thickening, and strut insertion. Both detection and correction steps are repeated until the problems have been eliminated. Our process is designed to create a model that is visually similar to the original model but possessing greater structural integrity.
