Composites Manufacturing & Simulation Center


Composites Manufacturing Simulation & Validation

  • Develop a comprehensive set of simulation tools that connect composites from their birth in manufacturing to their lifetime prediction.
  • Advance the certification of composite products by analysis validated by experiments and teach the use of these tools to the current and future generations of engineers.
  • Work with industry, academia, and government to put these tools in the hands of engineers.

Composites Additive Manufacturing

  • Predict and measure the anisotropic deformation that occurs in printed elements.
  • Include a description of anisotropic element shape change during deposition.
  • Anticipate performance of the printed element.

Mechanics of Structure Genome

  • Unify the length scales of structural mechanics and micromechanics.
  • Enable modeling of composites with the same accuracy and ease as metals.
  • Interface seamlessly with conventional FEA codes for high-fidelity composites modeling.
  • Simulate in the cloud using SwiftComp deployed on cdmHUB.

cdmHUB Online Composites Community

  • The Composites Design and Manufacturing HUB (cdmHUB).
  • Convene the composites community to advance certification by analysis.
  • The cdmHUB supports certification by analysis through developing and disseminating simulation best practices and through education and evaluation of composites simulation tools.

COHO 601-03 Leak Detection System from Convergent Manufacturing Technologies

  • Portable suite case
  • Standard model-1 wireless device

Rheometer DHR-2 from TA Instruments

  • Environmental test chamber kit
  • ARG22 Asphalt-para-plt accessory
  • Flowmeter
  • DMA
  • Film/fiber tension clamp
  • Gas cooling accessory

Digital Image Correlation (DIC) from CSI (Correlated Solutions Inc.)

  • CSI VIC-2D/3D laptop
  • Vic-Snap remote-control tablet
  • PGR Grasshopper3 5.0MP camera w/mount
  • NI 9215 4-channel C Series Voltage Input Module w/NI cDAQ-9171 BNC compact chassis
  • Schneider 8mm, 17m, 35mm lens
  • M30.5 x 0.5 polarizing filter

Dynamic Mechanical Analyzer (DMA) from TA Instruments

Five-axis CNC machine

Seven-axis FARO EDGE Laser Scanner from Faro Technologies

  • Laser line probe HD
  • Super Power User Notebook Computer
  • CAM2 Measure 10 software
  • Geomagic dongle

Injection Overmolding machine

High Pressure - RTM System from Cannon USA

Olympus stereoscope

LEICA DMI5000 Inverted Research Microscope from W. Nuhsbaum, Inc.

Two (2) three-axis CNC, Hass, VF1, 7500 rpm machines

Heated press, 250 ton, up to 1,000 degrees Fahrenheit

3 MTS load frames with 55-kip, 20-kip and 5-kip capacity and relevant fixtures for composites characterization

Digital Image Correlation

Olympus Automated Microscope

Permeability Characterization System

Fabric Draping Characterization System

Dynamic Scanning Calorimeter from TA Instruments

Thermogravimentric Analyzer from TA Instruments

Compression Press, 30 ton, up to 6,000 degrees Fahrenheit
